T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay

Name: T9SV1K1512 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay
Brand: TE Connectivity
Price: 1 USD

Buy cheap T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay product

Brand Name : TE Connectivity

Model Number : T9SV1K15-12

Place of Origin : Original Factory

MOQ : 5pcs

Price : Negotiate

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 5000pcs Per Mouth

Delivery Time : 3-5work days

Packaging Details : 50 Pcs

Product Category : General Purpose Relays

Description : 12V 35A 1 Form A SPST NO Solder Pin

Certification : Original Factory Pack

Mounting Style : Through Hole

Shipping by : DHL\UPS\Fedex\EMS\HK Post\TNT

Unit Weight : 1 oz

Part Aliases : 2027395-1

Contact Now

T9SV1K15-12 12VDC 35A 1 Form A SPST Power PCB Relay T9S Solder Pin General Purpose Relay

> Typical applications

Photovoltaic inverter

Electrical vehicle loading stations

Electrical vehicle

> Features

• 1 pole 35A, 1 form A (NO) contact

• Contact gap >1.5/1.8/2.1 mm options available

• 350mW hold power1) n Ambient temperature up to 85°C at 35A

• Meet VDE 0126-1-1 and IEC 62109-2

• Product in accordance to IEC 60335-1

• EN61095: AC7a at 85°C

T9SV1K15-12 12VDC 35A General Purpose Relays 1 Form A SPST Power Relay

> Safety Approval

VDE 40030974, UL E58304, TUV R50369970

> Coil Data

Rated coil voltage 12VDC

Coil insulation system according UL class F

> Specifications

Product Attribute	Attribute Value
Product Category:	General Purpose Relays
Product:	Power Relays
Type:	Standard
Coil Voltage:	12 VDC
Relay Contact Form:	1 Form A (SPST-NO)
Contact Current Rating:	35 A
Contact Termination:	Solder Pin
Mounting Style:	Through Hole
Switching Voltage:	277 VAC, 30 VDC
Coil Type:	Non-Latching
Coil Resistance:	64 Ohms
Coil Current:	188 mA
Contact Material:	Silver Nickel (AgNi)
Length:	32.5 mm
Width:	27.4 mm
Height:	20.4 mm
Contact Form:	SPST (1 Form A)

> Trading Guide

Shipping	Delivery period	For in-stock parts, orders are estimated to ship out in 3 days. Once shipped, estimated delivery time depends on the below carriers you chose: DHL Express, 3-7 business days. DHL eCommerce,12-22 business days. FedEx International Priority, 3-7 business days EMS, 10-15 business days. Registered Air Mail, 15-30 business days.
	Shipping rates	After confirming the order, we will evaluate the shipping cost based on the weight of the goods
	Shipping option	We provide DHL, FedEx, EMS, SF Express, and Registered Air Mail international shipping.
	Shipping tracking	We will notify you by email with tracking number once order is shipped.
Returning warranty	Returning	Returns are normally accepted when completed within 30 days from date of shipment.Parts should be unused and in original packaging.Customer has to take charge for the shipping.
Returning warranty	Warranty	All Retechip purchases come with a 30-day money-back return policy, This warranty shall not apply to any item where defects have been caused by improper customer assembly, failure by customer to follow instructions, product modification, negligent or improper operation
Ordering	Payment	T/T,PayPal, Credit Card includes Visa, Master, American Express.
