General Purpose Transistor IXTH200N10T 200A 100V 5.4 Rds 550W Dc Dc Converters

Name: General Purpose Transistor IXTH200N10T 200A 100V 54 Rds 550W Dc Dc Converters
Brand: IXYS
Price: 1 USD

Buy cheap General Purpose Transistor IXTH200N10T 200A 100V 5.4 Rds 550W Dc Dc Converters product

Brand Name : IXYS

Model Number : IXTH200N10T

Place of Origin : Original Factory

MOQ : 2pcs

Price : Negotiate

Payment Terms : T/T, Western Union, MoneyGram, PayPay

Supply Ability : 7000pcs Per Month

Delivery Time : 2-4work days

Packaging Details : 450Pcs

Type : MOSFET Transistors

Description : MOSFET 200 Amps 100V 5.4 Rds

Shipping by : DHL\UPS\Fedex

Lead time : 2-3Working days

Power - Max : 550W

Rise Time : 31 ns

Contact Now

General Purpose Transistor IXTH200N10T 200A 100V 5.4 Rds 550W Dc-Dc Converters

Description

Single MOSFET Die,N-Channel Enhancement Mode Avalanche Rated, Low Qg

IXYS Gen1 Trench Gate Power MOSFETs are ideally suited for low voltage/ high current applications,

requiring an exceedingly low RDS(ON), enabling very low power dissipation. This, combined with

wide-ranging operating junction temperature, from -40°C to 175°C, make them suitable candidates

for automobile applications and other similar demanding applications in harsh environments.

General Purpose Transistor IXTH200N10T 200A 100V 5.4 Rds 550W Dc Dc Converters

Features

• IXYS advanced low Qg process

• Low gate charge and capacitances - easier to drive - faster switching

• International standard packages

• Low RDS (on)

• Rated for unclamped Inductive load switching (UIS) rated

• Molding epoxies meet UL 94 V-0 flammability classification

Applications

• DC-DC converters

• Battery chargers

• Switched-mode and resonant-mode power supplies

• DC choppers z AC motor control

• Temperature and lighting controls

Specifications

Product Attribute	Attribute Value
Product Category:	MOSFET
Technology:	Si
Mounting Style:	Through Hole
Package / Case:	TO-247-3
Transistor Polarity:	N-Channel
Number of Channels:	1 Channel
Vds - Drain-Source Breakdown Voltage:	100 V
Id - Continuous Drain Current:	200 A
Rds On - Drain-Source Resistance:	5.5 mOhms
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 175 C
Channel Mode:	Enhancement
Tradename:	HiPerFET
Series:	IXTH200N10
Packaging:	Tube
Brand:	IXYS
Configuration:	Single
Fall Time:	34 ns
Height:	21.46 mm
Length:	16.26 mm
