IXFK27N80Q N Channel Mosfet Transistor 800V 27A 0.32 Rds Power MOSFETs HiPerFET

Product Categories
Shenzhen Retechip Electronics Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

IXFK27N80Q N Channel Mosfet Transistor 800V 27A 0.32 Rds Power MOSFETs HiPerFET

  • 1
  • 2
  • 3

Brand Name : IXYS

Model Number : IXFK27N80Q

Place of Origin : Original Factory

MOQ : 2pcs

Price : Negotiate

Payment Terms : T/T, Western Union, MoneyGram, PayPay

Supply Ability : 5000pcs Per Month

Delivery Time : 1-2work days

Packaging Details : 200Pcs

Type : MOSFET

Description : MOSFET 27 Amps 800V 0.32 Rds

Shipping by : DHL\UPS\Fedex

Lead time : 2-3Working days

Power - Max : 500W

Rise Time : 28 ns

Contact Now

IXFK27N80Q N Channel Mosfet 800V 27A 0.32 Rds Power MOSFETs HiPerFET

Description

HiPerFETTM Power MOSFETs Q-CLASS

Single MOSFET Die

N-Channel Enhancement Mode Avalanche Rated, Low Qg, High dV/dt, Low trr

IXFK27N80Q N Channel Mosfet Transistor 800V 27A 0.32 Rds Power MOSFETs HiPerFET IXFK27N80Q N Channel Mosfet Transistor 800V 27A 0.32 Rds Power MOSFETs HiPerFET

Features

• IXYS advanced low Qg process

• Low gate charge and capacitances - easier to drive - faster switching

• International standard packages z Low RDS (on) z Rated for unclamped Inductive load

   switching (UIS) rated

• Molding epoxies meet UL 94 V-0 flammability classification

Applications

• DC-DC converters z Battery chargers

• Switched-mode and resonant-mode power supplies

• DC choppers z AC motor control

• Temperature and lighting controls

  • Specifications
  • Product Attribute Attribute Value
    Product Category: MOSFET
    Si
    Through Hole
    TO-264-3
    N-Channel
    1 Channel
    800 V
    27 A
    320 mOhms
    - 20 V, + 20 V
    4.5 V
    170 nC
    - 55 C
    + 150 C
    500 W
    Enhancement
    Tube
    Brand: IXYS
    Configuration: Single
    Fall Time: 13 ns
    Forward Transconductance - Min: 20 S
    Height: 26.16 mm
    Length: 19.96 mm
    Product Type: MOSFET
