ADS1230IPWR Components IC 20bit Delta Sigma Adc Converter Chip
Premium Products
ADS1230IPWR Components IC 20bit Delta Sigma Adc Converter Chip
1
2
3
4
5
6
Brand Name :Texas Instruments
Model Number :ADS1230IPWR
Place of Origin :China
MOQ :10 pcs
Price :Negotiate
Payment Terms :T/T, Western Union, MoneyGram
Supply Ability :20000pcs Per Mouth
Delivery Time :1-2 work days
Packaging Details :2000Pcs/Reel
Product Category :ADC ic integrated circuit
Description :Analog to Digital Converters ADC 20 Bit Delta Sigma
Certification :Original Factory Pack
Warranty :90 Day
Shipping by :DHL\UPS\Fedex\EMS\HK Post\TNT
Unit Weight :0.002222g
Contact Now
ADS1230IPWR Integrated Circuit Components IC 20bit Analog To Digital Converter Chips
Applications
• Weigh Scales .
• Pressure Sensors.
• Industrial Process Control.
Specifications
Product Attribute
Attribute Value
Texas Instruments
Product Category:
Analog to Digital Converters - ADC
ADS1230
SMD/SMT
TSSOP-16
20 bit
1 Channel
I2C, SPI
80 S/s
Differential/Single-Ended
Sigma-Delta
2.7 V to 5.3 V
- 40 C
+ 85 C
Features:
50/60 Hz Rejection, Oscillator, PGA
Height:
1 mm
INL - Integral Nonlinearity:
6.29 LSB
Length:
5 mm
Moisture Sensitive:
Yes
Number of Converters:
1 Converter
Operating Supply Voltage:
3 V to 5.3 V
Pd - Power Dissipation:
7.7 mW
Power Consumption:
2.9 mW
Reference Type:
External
Shutdown:
No Shutdown
Supply Voltage - Max:
5.3 V
Supply Voltage - Min:
3 V
Width:
4.4 mm
Description
The ADS1230 is a precision 20-bit analog-to-digital converter (ADC). With an onboard low-noise programmable gain amplifier (PGA), onboard oscillator, and precision 20-bit delta-sigma ADC, the ADS1230 provides a complete front-end solution for bridge sensor applications including weigh scales,strain gauges, and pressure sensors.
The low-noise PGA has a gain of 64 or 128, supporting a full-scale differential input of ±39mV or ±19.5mV, respectively. The delta-sigma ADC has 20 Rejection at bit effective resolution and is comprised of a 3rd10SPS order modulator and 4th-order digital filter. Two data Measurements 60Hz rejection) and 80SPS. The ADS1230 can be clocked by the internal oscillator or an external clock source. Offset calibration is performed on-demand, and the ADS1230 can be put in a low-power standby mode or shut off completely in power-down mode.All of the features of the ADS1230 are controlled by Temperature Range dedicated pins; there are no digital registers to program. Data are output over an easily-isolated serial interface that connects directly to the MSP430
The ADS1230 is available in a TSSOP-16 package and is specified from –40°C to +85°C.
Features
• Complete Front-End for Bridge Sensor converter (ADC).
• Onboard PGA with Gain of 64 or 128
• Onboard Oscillator
• RMS Noise:
40nV at 10SPS (G = 128)
88nV at 80SPS (G = 128)
• 18-Bit Noise-Free Resolution
• Selectable 10SPS or 80SPS Data Rates ±19.5mV, respectively. The delta-sigma ADC has 20-
• Simultaneous 50Hz and 60Hz Rejection at bit effective resolution and is comprised of a 3rd10SPS
• External Voltage Reference up to 5V for rates are supported: 10SPS (with both 50Hz and Ratiometric Measurements
• Simple, Pin-Driven Control
• Two-Wire Serial Digital Interface
• Tiny 16-pin TSSOP Package
• Supply Range: 2.7V to 5.3V
• –40°C to +85°C Temperature Range
